Descriptions
TP-LINK TD-W8961N Features overview features network. Wi-Fi stable strong, a creating home, you are of the corner every to signal to transmit antennas high-gain 5dBi external Two Antennas Powerful applications. bandwidth-intensive other and gaming online HD, in streaming for perfect is TD-W8961N ports, LAN megabit band 2.4GHz the on speeds wireless 300Mbps With business small home solution cost-effective reliability superb with standard /ADSL /ADSL2 ADSL2+ rate full provides that device all-in-one robust incredibly a Router, NAT modem Combined
TP-LINK TD-W8961N Features:
- Wireless N speed up to 300Mbps
- Ideal for online gaming, Internet calls, and even the HD video streaming
- Easy Setup Assistant with multi-language support provides quick & hassle-free installation
- Easy one-touch wireless security encryption
- All-in-One Device: ADSL2+ Modem, NAT Router, 4-Port Switch, and Wireless N Access Point
- Wireless N speed up to 300Mbps
- Easy Setup Assistant with multi-language support provides quick & hassle-free installation
- Power On/Off Switch
- WPS Button
- Wi-Fi On/Off Button
- 4 10/100Mbps RJ45 Ports
- 1 RJ11 Port
TP-LINK TD-W8961N Specifications:
Brand: TP-Link
Series: N ADSL2
Model: TD-W8961N
Interface: 4 10/100Mbps RJ45 Ports // 1 RJ11 Port
Button:
1 Power On/Off Switch
1 WPS Button
1 Wi-Fi On/Off Button
External Power Supply: 9VDC/0.85A
IEEE Standards: IEEE 802.3, 802.3u
ADSL Standards Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite)
ITU-T G.994.1 (G.hs),
ITU-T G.995.1
ADSL2 Standards ITU-T G.992.3 (G.dmt.bis),
ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 7.7 * 5.1 * 1.4 in. (195 * 130 * 35 mm )
Antenna Type Omnidirectional, Fixed
Antenna Gain 2x5dBi
WIRELESS FEATURES
Wireless Standards IEEE 802.11n, 802.11g, 802.11b
Frequency 2.400-2.4835GHz
Transmit Power <20dBm(EIRP)
Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK,
Wireless MAC Filtering
Quality of Service QoS Remarking based on IPP/ToS, DSCP and 802.1p
Security NAT Firewall,
SPI Firewall,
MAC / IP / Packet / Application / URL Filtering,
Denial of Service(DoS),
SYN Flooding,
Ping of Death
Management Web Based Configuration(HTTP),
Remote management,
Telnet management,
Command Line Interface,
SSL for TR-069,
SNMP v1/2c,
SNMP over EOC,
Web Based Firmware Upgrade,
CWMP(TR-069),
Diagnostic Tools
Port Forwarding Virtual Server, DMZ, ACL(Access Control List)
VPN Pass-Through PPTP, L2TP, IPSec Pass-through
ATM/PPP Protocols ATM Forum UNI3.1/4.0,
PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516),
IPoA (RFC1577/2225),
PVC - Up to 8 PVCs
Advanced Features Traffic Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt;
Dynamic Host Configuration Protocol (DHCP), DHCP relay;
Network Address Translation (NAT);
PVC/Ethernet Port Mapping
VLAN, 802.1P,
Static Routing, RIP v1/v2 (optional);
DNS Relay, DDNS,
IGMP snooping V1/2
IGMP Multicast,
UPnP
Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
How to find the hardware version on a TP-Link device?
Some
TP-Link products may have more than one hardware version. For example,
a name ending with V1, V2, etc. Choose methods below to find the
hardware version of your TP-Link products. Using the label on the back
of the device.
- For most of products Using the engraved characters on the device
- For products (USB adapters) without labels: Using the management interface of the device
Download Firmware TP-LINK TD-W8961N
TD-W8961N_V1_141023
Tanggal Publikasi: 2014-10-23
Bahasa: Inggris
Ukuran File: 1.55 MB
Bug fixed:
1.Fixed the bug that when using Chrome,LAN setting can't be saved correctly and sometimes MAC address error displayed.
Notes:
1.For TD-W8961N_V1.
2.Your device’s configuration won't be lost after upgrading,which means you needn't to configure your device again after upgrading.
(Google Drive, Mediafire, Official)
TD-W8961N_V2_150630
Tanggal Publikasi: 2015-06-30
Bahasa: Inggris
Ukuran File: 1.66 MB
Modifications and Bug Fixes:
First firmware release of TD-W8961N_V2.0
Notes:
For TD-W8961N_V2.0
(Google Drive, Mediafire, Official)
TD-W8961N(EU)_V3_180118
Tanggal Publikasi: 2018-02-28
Bahasa: Inggris
Ukuran File: 1.88 MB
New Features/Enhancement
Optimized the stability of IPTV in wireless clients.
